The MJM 40z

An Agile Performer for a Stable ride

The 40z is an agile performer that parts the waves cleanly and deflects the wave action down and away for a soft, dry and stable ride. Fast, fuel efficient and ISO Category A Ocean certification distinguish the 40z as the undisputed best-in-class. Based on light but exceptionally strong epoxy construction and narrow, effective hull design, the 40z can best the competition by as much as 50% improvement in nautical miles per gallon at higher cruising speeds.

   REQUEST MORE INFORMATION

[vc_row full_width="stretch_row" css=".vc_custom_1604343594475{padding-top: 60px !important;}" el_class=".aboutC2A"] [vc_column width="1/4"][vc_single_image image="1498" alignment="center" onclick="custom_link" link="https://mjmyachts.com/contact/"][vc_column_text]

Ask a Question

[/vc_column_text][/vc_column] [vc_column width="1/4"][vc_single_image image="1493" alignment="center" onclick="custom_link" link="/wp-content/uploads/2021/07/40zBrochure.pdf"][vc_column_text]

40z® Brochure

[/vc_column_text][/vc_column] [vc_column width="1/4"][vc_single_image image="1495" alignment="center" onclick="custom_link" link="https://mjmyachts.com/schedule-a-drive/"][vc_column_text]

Schedule a Sea Trial

[/vc_column_text][/vc_column][vc_column width="1/4"][vc_single_image image="1500" alignment="center" onclick="custom_link" link="/wp-content/uploads/2021/07/40z_IPS_Manual.pdf"][vc_column_text]

40z® Manual

[/vc_column_text][/vc_column] [/vc_row]

40z Distinctions

  • Flush deck with side boarding doors at floating dock level
  • Fully-opening windshields (power option available)
  • US-built of tough, ultralight epoxy composite construction
  • Volvo Penta IPS joystick docking with DPS station-keeping
  • Seakeeper gyrostabilizer option

Key Features

  • 28.6 GPH / 1.1nmpg at 32.5 knot cruising speed
  • ISO Certified Category A Ocean

Principal Dimensions

  • Length Overall w / Swim Platform & Bow Rolle 44'
  • Length on Deck 40'
  • Beam 12'
  • Draft Twin IPS 3' 3-1/2“
  • Deadrise/Transom 18.5°
  • Fuel Capacity 350 gal
  • Standard Power Twin 370hp IPS 500
  • Optional Power Twin 435hp IPS 600
  • Displacement 1/2 Load 18,774 lb
  • Weight Capacity 3,348 lb
  • Max Headroom 6‘ 4“
  • Max Persons 16
  • Water Capacity 100 gal
  • Air Height (w/Radar) 9‘ 9“
  • Range @ 32.5 kts 1.1 nmpg 342 nm

Schedule A Sea Trial

Request More Information

Contact us to learn more about the 40z

A Zurn Design
